- Filter pump specially designed for large ponds
- Impressive flow rates, from 10,000-18,000 lph
- Range can handle coarse pumping of particles up to 6 mm
What are Oase AquaMax Gravity Eco Pond Pumps?
The Oase AquaMax Gravity Eco Pump range are energy-efficient pumps with impressive flow rates from 10,000-18,000 lph. Designed for larger ponds, especially koi ponds with gravity led filtration systems, the Gravity Eco range can easily handle particles of up to 6 mm and have a 50mm hose size.
Key Features:
- Energy-efficient
- 10,000-18,000lph flow rate
- 6mm solids-handling capacity
- Stainless steel cage
- Easy to maintain
- 5-year guarantee
- Three models to choose from
- 25-40 mm hose size
- Great for koi ponds
What are the features of AquaMax Gravity Eco?
The unit has a stainless steel cage, which makes maintenance easier by keeping out any large pieces of waste. With all-new electronically controlled electric motors and clever impeller design, these impressive solids-handling pumps are backed by a 5-year guarantee. The removable base enables pump installation in confined spaces, while the included adapter set enables the connection of hoses and pipes.
What size pump do I need for my pond?
Selecting what size pond pump to run your filtration system is one of the most important things to consider when setting up your pond. Pump flow rates drop when you pump higher and further than the pond, so you need to consider these effects. You should aim to purchase a pump that meets the maximum flow rate of your filter at its height above pond level. Check out our help guide for more information about how to select the right size pump for your pond.
What fittings will I need to install this pump?
You'll need to consider how you'll get power to your pump. To comply with UK electrical legislation, pond appliances can't be supplied with a fitted plug, so you'll need to purchase one separately or wire it into an outdoor plug socket. A 10 m cable is provided, but these do not come with a fitted plug. You'll also need some ribbed anti-kink pond hose and hose clips to keep the hose firmly attached to the pump.
Features
Energy efficiency | A* |
Cable length | 10m |
Dimensions | All pumps: L 27.2cm x W 14.2cm x 18.2cm |
Thermal cut off | Yes |
Solids handling capacity | Up to 6mm |
Setup type | Underwater and dry installed |
Hose size | 25-40mm |
Fitted plug | To comply with UK electrical legislation, pond appliances can't be supplied with a fitted plug, so you'll need to purchase one separately or wire it into an outdoor plug socket. |
Guarantee | 3 + 2 years |
Pond sizes | Large, especially Koi ponds |
Specification
Pump model | Power | Max head height | Max flow rate |
10000 | 65W | 1.3m | 10,000lph |
15000 | 85W | 1.8m | 15,000lph |
20000 | 120W | 2.2m | 18,000lph |
Oase Aquamax Gravity Eco Pond Pump Flow Curve Chart
Values applicable for each pump when running at 100% power
Pump model | 1m | 2m | 3m |
10000 | 4,200lph | - | - |
15000 | 10,200lph | - | - |
20000 | 12,600lph | 3,000lph | - |
-
